Super Duralumin alloy aluminum Billet 2025 forged aluminum for Aeroplane propeller
2025 forged aluminum Quickly details
2025 aluminum alloy T6 Mechanical properties:
|
Tensile strength (kg/mm2) |
yield point, elongation(kg/mm2) | Elongation(%) |
brinell hardness
|
shear strength(kg/mm2)
|
fatigue strength(kg/mm2) |
| 10.78 | 26.01 | 19 | 110 | 24.61 | 12.66 |
Normal size:Φ166,Φ220,Φ380,Φ396,Φ448,Φ462,Φ566,Φ582,Φ915,Φ1060,Φ1220,Φ1320
Features:
Large specification :the produced billetφ1320mm is the largest billet in the world.
The max : weight of the billet up to 12.5 ton.
High purity : low hydrogen, low dross, low alkali content inside the ingot .
high-homogeneity : composition & organization, Small degree of segregation.small grain
size difference between core and surface.
Fine grain size.
Availability of product with the hydrogen content ≤0.08ML/100gAl.
Availability of product with porosity at class one .
Availability of product with oxidation film at the class one.
Availability of product with ultrasonic flaw detection at level A.
2025 forged aluminum Application:
Aeroplane propeller
2025 Chemical Composition Standard.
| Cu | Mg | Mn | Fe | Si | Zn | Ti | Cr | Other | Al |
| 3.8-4.9 | 1.2-1.8 | 0.3-0.9 | 0.5 | 0.5 | 0.25 | 0.15 | 0.1 | <0.05 | Balance |
2025 forged aluminum alloy & forging product size.
| Alloy | 2025 forged aluminum Products size | |
|
Diameter (mm) |
Max. length (mm) |
|
|
2xxx/2025
|
Φ166 | 7500 |
| Φ220 | 7500 | |
| Φ380 | 7500 | |
| Φ396 | 7500 | |
| Φ448 | 7500 | |
| Φ462 | 7500 | |
| Φ566 | 7500 | |
| Φ582 | 7500 | |
|
2xxx/2025 |
Φ915 | 4500 |
| Φ1060 | 4000 | |
| Φ1220 | 4000 | |
| Φ1320 | 3500 | |
Remark:
1. Billet peeling is available.
2. The cut-to-length product is available upon to customer’s request.
Aluminium forging alloy & forging product application.
| Alloy | forging product application |
| 2025 | Aeroplane propeller |
2025 forged aluminum
