| Place of Origin: | CHINA |
| Brand Name: | JIMA |
| Certification: | ISO9001-2008,SGS,ROHS. |
| Model Number: | 7475 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | wooden pallet |
| Delivery Time: | 20~30days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000 per month |
| Application: | Airplane, Ship, Auto Parts, Structural Member | Name: | 7475 Super Duralumin Aluminum Alloy Billet |
|---|---|---|---|
| Standard: | JIS, DIN, BS, ASTM, SAE. | Type: | Casting Forging |
| Technics: | Forge, CNC | Alloy: | 7475 |
| Diamerer: | Max 1320mm | Lenght: | Max 7500mm |
| High Light: | billet aluminum bar stock,billet premium aluminium |
||
EN AW-7075 A97475 AlZn5.5MgCu(A) 7475 Super duralumin aluminum alloy Billet for Airplane,ship,auto parts, structural.
Application:
Super duralumin EN AW-7075 A97475 AlZn5.5MgCu(A) 7475 aluminum alloy Billet,
Extra-super duralumin aluminum alloy Billet used for Airplane, ship, auto parts, structural member.
Quickly details.
Alloy:7475:
Max diameter: 1320mm.
Max length : 7500mm.
(AA) 7475,UNS A97475,ISO R209 AlZn5.5MgCu(A), GB 7475
Deformation of 7475 aluminum alloy, the aluminum and aluminum alloy. 7475 belong to Al - zinc - - Cu alloy, Mg 7475 used in the fuselage with bags and bags of aluminum plate, aluminum wing skeletons, purlin, etc and the other is to have high strength and fracture toughness of the parts.
Features:
Large specification :the produced billetφ1320mm is the largest billet in the world.
The max : weight of the billet up to 12.5 ton.
High purity : low hydrogen, low dross, low alkali content inside the ingot .
high-homogeneity : composition & organization, Small degree of segregation.small grain
size difference between core and surface.
Fine grain size.
Availability of product with the hydrogen content ≤0.08ML/100gAl.
Availability of product with porosity at class one .
Availability of product with oxidation film at the class one.
Availability of product with ultrasonic flaw detection at level A.
7475 Chemical Composition Standard.
| Cu | Mg | Mn | Fe | Si | Zn | Ti | Cr | Other | Al |
| 1.2-1.9 | 1.9-2.6 | 0.06 | 0.12 | 0.1 | 5.2-6.2 | 0.06 | 0.18-0.25 | <0.15 | Balance |
Package: wooden pallet.
FAQ:
Q1:How many quantity for 40'GP load?
A:Aprrox.25 tons.
Q2:how many staff do you have ?
A:We have 380 workers.
Q3: How can get quotation ?
A:In order to offer right quotation, we need know the alloy ,temper,thickness,width,length,application and quantity etc.
Q4. How many tons you can supply each month?
We can offer more than 40000 tons each month.
Q5.What payments your company can accept?
T/T, L/C.
Q6.will be ship out which port?
-Shanghai port, Qingdao,Ningbo port, tianjin prot.
Q27.Are the package suitable For export ?
Yes , it is suitable for export.
Q28.Would you accept delivery spread over a period of time ?
A:Yes,we can.
Our Services
(1): High quality products with reasonable price.
(2): Samples can be provided as your requirements. Free sample
(3): We have more than 4 years experience in exporting products to worldwide countries, can provide the high quality products.
(4): We have five thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and 7-day 24-hour services.
(5): Wide excellent experiences with after-sale service.
Aluminium forging alloy & forging product size.
| Alloy | Products size | |
|
Diameter (mm) |
Max. length (mm) |
|
|
2xxx 4xxx 5xxx 6xxx 7xxx |
Φ166 | 7500 |
| Φ220 | 7500 | |
| Φ380 | 7500 | |
| Φ396 | 7500 | |
| Φ448 | 7500 | |
| Φ462 | 7500 | |
| Φ566 | 7500 | |
| Φ582 | 7500 | |
|
2xxx 7xxx |
Φ915 | 4500 |
| Φ1060 | 4000 | |
| Φ1220 | 4000 | |
| Φ1320 | 3500 | |
Remark:1. Billet peeling is available.
2. The cut-to-length product is available upon to customer’s request.
Aluminium forging alloy & forging product application.
| Alloy | forging product application |
| 2024 | Airplane, truck hub, ordnance, railway vehicles, machine structure |
| 2025 | Aeroplane propeller |
| 2218 | Airplane engine cylinder head and piston |
| 2219 | The rocket liquid fuel tank, work structure for long time high temperature ,welding structure, vehicle material |
| 2618 | Airplane cylinder head and piston hub, jet motor accessories, rubber mold, General heat-resistant parts,ect |
| 5083 | Military ballistic rocket parts, marine high strength welded structures, flange plate for liquefied natural gas, petrochemical machinery, ships and warships parts, sea water desalination structure |
| 5056 | flange plate for liquefied natural gas, petrochemical machinery, ships and warships parts, sea water desalination structure |
| 5456 | military rocket trajectory ballistic fist-size pile piece, marine high strength welded structures |
| 6061 | Truck component, automobile hub, flange, chemical industry & water heater |
| 6070 | aerospace, large-scale automobile vehicle, railway vehicle material & rotor parts |
| 6082 | |
| 6005A | supercharger fan, high speed train carriage material & transportation machinery parts, ect |
| 6151 | the airplane engine box, auto parts, machine part,ect |
| 7049 | aerospace vehicle structure |
| 7079 | Skeleton large forgings |
| 7075 | Airplane, ship, auto parts, structural member |
| 7175 | |
| 7475 | |
| 7050 | high stress components, especially key components and aerospace materials and important structural materials |
| 7150 |
