Forging Products Aluminium Alloy 5083 , Marine Grade Aluminium 5083 LF4 AlMg4.5Mn0.7

Forging Products Aluminium Alloy 5083 , Marine Grade Aluminium 5083 LF4 AlMg4.5Mn0.7

    • Forging Products Aluminium Alloy 5083 , Marine Grade Aluminium 5083 LF4 AlMg4.5Mn0.7
  • Forging Products Aluminium Alloy 5083 , Marine Grade Aluminium 5083 LF4 AlMg4.5Mn0.7

    Product Details:

    Place of Origin: CHINA
    Brand Name: JIMA
    Certification: ISO9001-2008,SGS,ROHS.
    Model Number: 5083

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiations
    Price: Negotiations
    Packaging Details: wooden pallet
    Delivery Time: 20~30days
    Payment Terms: T/T, L/C
    Supply Ability: 1000 per month
    Contact Now
    Detailed Product Description
    Application: Ships And Warships Parts, Sea Water Desalination Structure Name: 5083 Aluminium Forging Products
    Standard: JIS, DIN, BS, ASTM, SAE. Type: Casting Forging
    Technics: Forge, CNC Alloy: 5083,LF4,AlMg4.5Mn0.7,A5083,EN AW-5083
    High Light:

    aluminium alloy billet

    ,

    billet aluminum bar stock

    Super Duralumin 5083 aluminium forging products LF4 AlMg4.5Mn0.7 A5083 EN AW-5083.



    5083 aluminium forging products Application:

    Military ballistic rocket parts, marine high strength welded structures, flange plate for liquefied natural gas, petrochemical machinery, ships and warships parts, sea water desalination structure.



    Quickly details.

    Alloy: 5083(LF4):

    5083 aluminum alloy is high magnesium alloy, in not heat treated alloy strength is good, excellent corrosion resistance, can be cutting.



    Max diameter: 1320mm.

    Max length : 7500mm.

    Normal size:Φ166,Φ220,Φ380,Φ396,Φ448,Φ462,Φ566,Φ582,Φ915,Φ1060,Φ1220,Φ1320.



    5083 aluminium Mechanical properties:

    Tensile strength of sigma b (MPa) : p. 270.

    Conditions to yield strength sigma (0.2 MPa) : p. 110.

    Elongation delta (%) : 10 or 20.

    Elongation delta (%) : 12 or more.



    5083 aluminum alloy Features:

    Large specification :the produced billetφ1320mm is the largest billet in the world.

    The max : weight of the billet up to 12.5 ton.

    High purity : low hydrogen, low dross, low alkali content inside the ingot .

    high-homogeneity : composition & organization, Small degree of segregation.small grain

    size difference between core and surface.

    Fine grain size.

    Availability of product with the hydrogen content ≤0.08ML/100gAl.

    Availability of product with porosity at class one .

    Availability of product with oxidation film at the class one.

    Availability of product with ultrasonic flaw detection at level A.



    5083 aluminum alloy is high magnesium alloy, in not heat treated alloy strength is good, excellent corrosion resistance, can be cutting. After the anodized surface is beautiful. Good welding performance. 5083 the main alloy elements for magnesium alloy, with good corrosion resistance and weldability, and moderate intensity. Excellent corrosion resistance make 5083 alloy is widely used in Marine applications such as ships, cars, planes and weldment, subways, light rail, the need for stringent fire prevention of the pressure vessel (such as liquid tanker, refrigerated trucks, refrigerated container), cooling device, television tower, drilling equipment, transportation equipment, missile component armor.



    Aluminum 5083 alloy Chemical Composition Standard.



    Cu Mg Mn Fe Si Zn Ti Cr Other Al
    0.1 4.0-4.9 0.04-0.1 0.4 0.4 0.25 0.15 0.05-0.25 <0.15 Balance



    Alloy 5083-H12 Mechanical properties.



    Tensile strength

    (kg/mm2)

    yield point, elongation(kg/mm2) Elongation(%)

    brinell hardness



    shear strength(kg/mm2)



    fatigue strength(kg/mm2)
    31 19.7 8 80 12.3 15.5





    Aluminium forging alloy & forging product size.

    Alloy Products size

    Diameter

    (mm)

    Max. length

    (mm)

    5083



    Φ166 7500
    Φ220 7500
    Φ380 7500
    Φ396 7500
    Φ448 7500
    Φ462 7500
    Φ566 7500
    Φ582 7500

    Remark:1. Billet peeling is available.
    2. The cut-to-length product is available upon to customer’s request.



    5083 Aluminium forging alloy & forging product application.



    Alloy forging product application
    5083 Military ballistic rocket parts, marine high strength welded structures, flange plate for liquefied natural gas, petrochemical machinery, ships and warships parts, sea water desalination structure
